CodelistGenerator

CRAN status codecov.io R-CMD-check Lifecycle:Stable R-CMD-check

Installation

You can install CodelistGenerator from CRAN

install.packages("CodelistGenerator")

Or you can also install the development version of CodelistGenerator

install.packages("remotes")
remotes::install_github("darwin-eu/CodelistGenerator")

Example usage

library(dplyr)
library(CDMConnector)
library(CodelistGenerator)

For this example we’ll use the Eunomia dataset (which only contains a subset of the OMOP CDM vocabularies)

db <- DBI::dbConnect(duckdb::duckdb(), dbdir = eunomia_dir())
cdm <- cdm_from_con(db, cdm_schema = "main", write_schema = c(prefix = "cg_", schema = "main"))

Exploring the OMOP CDM Vocabulary tables

OMOP CDM vocabularies are frequently updated, and we can identify the version of the vocabulary of our Eunomia data

getVocabVersion(cdm = cdm)
#> [1] "v5.0 18-JAN-19"

CodelistGenerator provides various other functions to explore the vocabulary tables. For example, we can see the the different concept classes of standard concepts used for drugs

getConceptClassId(cdm,
                  standardConcept = "Standard",
                  domain = "Drug")
#> [1] "Ingredient"          "Quant Clinical Drug" "Branded Drug"
#> [4] "Quant Branded Drug"  "Clinical Drug Comp"  "Branded Drug Comp"
#> [7] "CVX"                 "Clinical Drug"       "Branded Pack"

Vocabulary based codelists using CodelistGenerator

CodelistGenerator provides functions to extract code lists based on vocabulary hierarchies. One example is `getDrugIngredientCodes, which we can use, for example, to get all the concept IDs used to represent aspirin.

getDrugIngredientCodes(cdm = cdm, name = "aspirin")
#>
#> - aspirin (2 codes)

If we also want the details of these concept IDs we can get these like so.

getDrugIngredientCodes(cdm = cdm, name = "aspirin", withConceptDetails = TRUE)
#> $aspirin
#> # A tibble: 2 × 4
#>   concept_id concept_name              domain_id vocabulary_id
#>        <int> <chr>                     <chr>     <chr>
#> 1   19059056 Aspirin 81 MG Oral Tablet Drug      RxNorm
#> 2    1112807 Aspirin                   Drug      RxNorm

And if we want codelists for all drug ingredients we can simply omit the name argument and all ingredients will be returned.

ing <- getDrugIngredientCodes(cdm = cdm)
ing$aspirin
#> [1] 19059056  1112807
ing$diclofenac
#> [1] 1124300
ing$celecoxib
#> [1] 1118084

Systematic search using CodelistGenerator

CodelistGenerator can also support systematic searches of the vocabulary tables to support codelist development. A little like the process for a systematic review, the idea is that for a specified search strategy, CodelistGenerator will identify a set of concepts that may be relevant, with these then being screened to remove any irrelevant codes by clinical experts.

We can do a simple search for asthma

asthma_codes1 <- getCandidateCodes(
  cdm = cdm,
  keywords = "asthma",
  domains = "Condition"
)
asthma_codes1 %>%
  glimpse()
#> Rows: 2
#> Columns: 6
#> $ concept_id       <int> 4051466, 317009
#> $ found_from       <chr> "From initial search", "From initial search"
#> $ concept_name     <chr> "Childhood asthma", "Asthma"
#> $ domain_id        <chr> "Condition", "Condition"
#> $ vocabulary_id    <chr> "SNOMED", "SNOMED"
#> $ standard_concept <chr> "S", "S"

But perhaps we want to exclude certain concepts as part of the search strategy, in this case we can add these like so

asthma_codes2 <- getCandidateCodes(
  cdm = cdm,
  keywords = "asthma",
  exclude = "childhood",
  domains = "Condition"
)
asthma_codes2 %>%
  glimpse()
#> Rows: 1
#> Columns: 6
#> $ concept_id       <int> 317009
#> $ found_from       <chr> "From initial search"
#> $ concept_name     <chr> "Asthma"
#> $ domain_id        <chr> "Condition"
#> $ vocabulary_id    <chr> "SNOMED"
#> $ standard_concept <chr> "S"

We can compare these two code lists like so

compareCodelists(asthma_codes1, asthma_codes2)
#> # A tibble: 2 × 3
#>   concept_id concept_name     codelist
#>        <int> <chr>            <chr>
#> 1    4051466 Childhood asthma Only codelist 1
#> 2     317009 Asthma           Both

We can then also see non-standard codes these are mapped from, for example here we can see the non-standard ICD10 code that maps to a standard snowmed code for gastrointestinal hemorrhage returned by our search

Gastrointestinal_hemorrhage <- getCandidateCodes(
  cdm = cdm,
  keywords = "Gastrointestinal hemorrhage",
  domains = "Condition"
)
Gastrointestinal_hemorrhage %>%
  glimpse()
#> Rows: 1
#> Columns: 6
#> $ concept_id       <int> 192671
#> $ found_from       <chr> "From initial search"
#> $ concept_name     <chr> "Gastrointestinal hemorrhage"
#> $ domain_id        <chr> "Condition"
#> $ vocabulary_id    <chr> "SNOMED"
#> $ standard_concept <chr> "S"

Summarising code use

summariseCodeUse(list("asthma" = asthma_codes1$concept_id),
                 cdm = cdm) %>%
  glimpse()
#> Rows: 6
#> Columns: 13
#> $ result_id        <int> 1, 1, 1, 1, 1, 1
#> $ cdm_name         <chr> "Synthea synthetic health database", "Synthea synthet…
#> $ group_name       <chr> "codelist_name", "codelist_name", "codelist_name", "c…
#> $ group_level      <chr> "asthma", "asthma", "asthma", "asthma", "asthma", "as…
#> $ strata_name      <chr> "overall", "overall", "overall", "overall", "overall"…
#> $ strata_level     <chr> "overall", "overall", "overall", "overall", "overall"…
#> $ variable_name    <chr> "overall", "Childhood asthma", "Asthma", "overall", "…
#> $ variable_level   <chr> NA, "4051466", "317009", NA, "4051466", "317009"
#> $ estimate_name    <chr> "record_count", "record_count", "record_count", "pers…
#> $ estimate_type    <chr> "integer", "integer", "integer", "integer", "integer"…
#> $ estimate_value   <chr> "101", "96", "5", "101", "96", "5"
#> $ additional_name  <chr> "overall", "source_concept_name &&& source_concept_id…
#> $ additional_level <chr> "overall", "Childhood asthma &&& 4051466 &&& conditio…
